Bar Bending Machine

ADVANTAGES:
1. Latest heavy-duty gear box assembly, spindle is maintenance free.
2. Column and spool adopt high quality alloy steel, high temperature quenching treatment, higher hardness, more wear-resisting.
3. Extra hardened Disc & Square steel to prevent deformation and bend Bars more accurately.
4. Enclosed electric cabinet protects from moisture, dust and leakage
5. Thick dashboards to increase the integrity of the machine and for longer service life
6. Double sided operation to operate in tow realizations conveniently and quickly
7. Rotary oil-way of workstation makes adding oil more conveniently.
8. Advanced Electrical Control Panel with brake motor increases performance and durability.
9. Different Bending Bushes designed for various bending radius.
10. Ensures high durability at its user ends, effectively increases the production capactiy.
11. Various sizes of bushes for bending diameter of bars.
12. Cost effective bending machines, used for bending reinforcement bars and different kind of round bars.
Get A Quote
Description
Automatic Bar Bending Machines (MBB 40 & MBB 50) offered by us are designed for bending bars from 6mm to 42 mm. These bar bending machines are served in the capacity of 4HP & 5HP Power. These Machines are high on demand for Construction Job Site applications. The range of Bar Bending Machines that we offer renders smooth functioning for longer time period. In addition, the high performance of our Reinforced Bar Bending Machine with working rotation speed. MBB 40 & MBB 50 is powered by 100% copper winding TEFC induction electric motor running on 4P, 415v. Our Fully Automatic Bar Bending Machine is operated through manual button as well as automatic button and Delivers stable performance with optimum safety .
Product Feature
Model
MBB 40
MBB 50
Operation
Automatic /  Semi
Automatic /  Manual
Automatic /  Semi
Automatic /  Manual
Bar Bending Dia.
6mm to 32 mm
6mm to 42 mm
Type of Motor
Copper Winding (Brake Motor)
Copper Winding (Brake Motor)
Motor Power
4 HP
5 HP
Motor Rotation Speed
1440 R/min
1440 R/min
Speed of Working Disk
8-11 R/min
12 R/min
Noise Value (1m away)
≤80 dB(A)
≤80 dB(A)
Weight
440Kg.
490Kg.
Dimension
≤80 dB(A)
≤80 dB(A)
Production Capacity
2 Ton P/h
2 Ton P/h
